Product Description
EMHC-2000-6 honeycomb papercore machine is one full automatic line to produce honeycomb papercore continuously. No need for paper cutter and honeycomb paper connecting machine. Production flow is
Paper rolls Feeding-gluinglaminating and pullHorizontal cutting Core paper conveyor Core paper slottingCore paper pulling upstacking
| Max. paper roll width | 2000mm |
| Max. paper roll diameter | 1300mm |
| Max. mechanical speed | 800 cuts/min |
| Honeycomb core thickness range | 8-100mm |
| Tolerance of honeycomb thickness | -/+0.3mm |
| Production line dimensions(L*W*H) | 30000mm*4500mm*3000mm |
| Max. paper roll number | 6 rolls |
| Total power | 90KW |
Advanced Automation and EfficiencyThis production line integrates a PLC-based system for thorough process control and accuracy. Its automation minimizes manual intervention, boosting productivity and ensuring uniform quality across all outputs. Operators benefit from intuitive interfaces and reduced labor requirements.
Versatile Application RangeCapable of producing both single and double-faced panels, honeycomb cores, and custom partitions, this system handles kraft and corrugated paper with customizable cutting sizes up to 1600 mm wide. Its adaptability suits various industrial needs and product specifications.
Safety and Reliable OperationSafety is prioritized with features such as emergency stops and protective covers. Operating within a temperature range of 5C-40C and designed for dust-free, humidity-controlled settings, the production line ensures optimal, long-term functionality and operator peace of mind.
Comprehensive Support and InstallationProfessional installation services are available on-site, accompanied by ongoing technical support and easy access to spare parts. This guarantees a smooth start-up and minimizes downtime, facilitating consistent, high-quality production.
FAQ's of Fully automatic paper honeycomb core and panel production line:
Q: How does the fully automatic paper honeycomb core and panel production line ensure precise glue application?
A: The production line uses an automated glue application system featuring accurate dosage control. This ensures consistent and efficient bonding across panels and honeycomb cores, enhancing product strength while minimizing material waste.
Q: What is the recommended environment for optimal operation of this production line?
A: Optimal operation requires a dust-free, humidity-controlled facility, helping to maintain the integrity of kraft and corrugated paper and ensuring reliable machine performance and consistent product quality.
Q: When is on-site installation service available for this production line?
A: On-site installation services are provided upon delivery and setup of the equipment, tailored to your schedule and location. Expert technicians ensure correct assembly, calibration, and operator training.
Q: Where can this production line be installed and who are the suitable users?
A: This production line is designed for industrial environments, suitable for distributors, manufacturers, exporters, suppliers, and traders requiring high-capacity paper honeycomb panel and core production.
Q: What materials and product sizes can be processed on this system?
A: It handles kraft and corrugated paper with core cell sizes ranging from 6 mm to 25 mm, panel thicknesses from 3 mm to 100 mm, and customizable widths up to 1600 mm.
Q: How many operators are needed and what safety features are included?
A: Efficiently run by just 1-2 operators, the line is equipped with emergency stop buttons and safety guard covers to protect staff during operation.
Q: What are the main benefits of using this automated production line?
A: The line offers high output (3000-7000 sqm/8h), precise control, minimal manual labor, and versatile application, producing consistent, high-quality honeycomb panels and cores for diverse industrial use.
