Paper Egg Tray Forming Machine

Paper Egg Tray Forming Machine
Paper Egg Tray Forming Machine
Send Inquiry
Product Code : 01
Product Description

The Paper Egg Tray Forming Machine helps in forming platens and of transferring platen. These machines are automatic and is also capable of using waste paper as raw materials to manufacture various size egg tray. The Paper Egg Tray Forming Machine is made under the guidance of skilled workers using sophisticated techniques and modern machinery. Further, they have simple structure but but is capable of forming trays effectively. They are also tested by our quality assurance team to ensure they are free from defects.

Features:

  • Capacity:30-packed egg tray:2500~2800pcs/h;
  • Workshop: more than 600m2.(length>=50m,width>=12m).
  • Electricity consumption: about 140KW. ( 210KW installed ).
  • Water consumption: 600~700kgs/hour
  • Kind of Raw material: newspaper, carton paper
  • Material consumption: 170~180kgs/h.
  • Steam consumption: 1.0 ton~1.2 ton per hour(1.0~1.2MPa saturated steam)
  • Workers:4~5person
  • Transport: the machine needs 8 of 40HQ containers for loading.

Specification:

Pulp making system
Waste paper conveyer 1.1KW
Hydraulic  Pulper 2.5m3  37KW
Work table for the hydraulic pulper Matching for the Hydraulic  Pulper
Pulp   filter 4KW
Pulp   pump DN80  4KW
Water pump DN80  1.5KW
Pulp   pond beater 1.5KW
Automatic   density control 0.6%~2%
Electric cabinet for the pulp making system Regulated pulp crusher,   pulp pump, Pulp vat mixer
The main electronic parts brand: Siemens;


forming system
Automatic   reciprocating forming machine
Forming mould for 30-eggs tray 1pcs/mould
Transfer   mould 1pcs/mould
Water ring   vacuum pump SKA-253    55KW
Water pump   DN40  1.5KW
Vacuum   subnormal pressure container 4m3
Water discharge container 1.5m3
Electric cabinet   for vacuum system Regulated vacuum pump,  water pump ;
The main electronic parts brand: Siemens


drying system
Drying product line
(steam   heating)
Ø
Electronic   control cabinet for drying line Control the dryer running, temperature control Include the wire from control cabinet to   each parts.
Collecter C-6
Air compressor

Compressed air dryer

Compressed  Air pot 1m3
Air filter Q,P,S
Spot welding machine NYD-II
Packer EM
